1.1. Governing bodies and devices

1.1.1. Release models till January, 1988.

1.1.1.1. Dashboard

GENERAL INFORMATION

The dashboard of models of release till January, 1988.

1 – lateral vozdukhoduv. The direction of a stream of air is down regulated by turn of a lattice of a vozdukhoduv, and across – the handle on a lattice of a vozdukhoduv;
2 – dashboard;
3 – a ware box for small things;
4 – the handle of control of distributive gates, has four provisions.
At position of the handle, to the corresponding symbol air comes to salon through lateral 1 and the central 35 vozdukhoduva, to feet of the driver and passenger, on wind and lateral glasses air does not move.
At the position of the handle corresponding to a symbol air arrives to feet of the driver and passenger, through vozdukhoduva 1 and 35, on wind and lateral glasses air does not move.
At the position of the handle corresponding to a symbol the main part of air arrives to feet of the driver and passenger through vozdukhoduva 1 and 35, the insignificant part of air moves on wind and lateral glasses.

At the position of the handle corresponding to a symbol all air arrives on having blown wind and lateral glasses, to feet of the driver and passenger, and also through vozdukhoduva 1 and the 35th air does not arrive.

5 – the lighter, turns on pressing the handle against the stop. The spiral of the lighter heats up for 10–20 with and the lighter with click comes back to a starting position. Repeatedly the lighter is allowed to be turned on approximately through 20 with;
6 – the heater fan electric motor switch handle, has five provisions: in extreme left situation the fan of a heater is switched off, in extreme by the right – the maximum speed of the fan is included, provisions I, II and III are intermediate;
7 – the handle of adjustment of air temperature, coming to salon. At turn of the handle to the right air temperature increases, and at turn to the left – decreases;
8 – ashtray;
9 – switch of heating of back glass. Heating joins at the included ignition, thus the control lamp in a combination of devices lights up;
10 – switch of fog lights and back fog lamps. At inclusion of headlights and lamps the control lamp in a combination of devices lights up;
11 – the switch (lock) of ignition, has three provisions of a key: I – all consumers are switched off, the key is taken out, at the taken-out key the steering is locked by the anti-theft device; By II – ignition and all consumers of the electric power (lighting, radio equipment, a screen wiper, etc.) is included, the key is not taken out, the steering is not locked; By III – ignition and a starter is included. The key is not taken out. The steering is not locked. This provision of a key not fixed. If to release a key, it comes back under the influence of a spring to situation II;
12 – the switch of a sound signal, is located under a soft overlay of a steering wheel. When pressing a slip the sound signal joins;
13 – ware shelf;
14 – the ABS switch, works when pressing it. Thus the control lamp in a combination of devices lights up. By repeated pressing the switch the system joins;
15 – the handle of the electroproofreader of headlights, has four provisions: 0 – in the car there are a driver and the passenger on a forward seat; 1 – in the car there are five people, without freight in a luggage carrier; 2 – full loading; 3 – in the car there is a driver, the luggage carrier is completely loaded;
16 – the handle of the regulator of frequency of rotation of a cranked shaft of the cold engine (cars with diesel engines). At rotation of the handle clockwise the frequency of rotation increases, counterclockwise – decreases. Changing rotation frequency, reduce vibration of not heated-up engine;
17 – cowl lock drive handle. To open a cowl, the handle is extended on itself;
18 – decorative lattice of a nozzle of an obduv of lateral glasses;
19 – decorative lattices of the dashboard, under them are established loudspeakers;

20 – the lever of the switch of indexes of turns and light of headlights, can be installed in the following provisions: I – all consumers are switched off; II – are included indexes of the right turn; III – are included indexes of the left turn; IV – turned on a driving beam of headlights (at position III of the lever 21); V – the passing beam of headlights (is turned on at position III of the lever 21). Headlights and indexes of turns work only at the included ignition. At the switched-off ignition by the lever 20 parking fires in headlights and back lamps join. In position II of the lever 20 parking fires on the right side of the car, in situation III – on the left side are included;

21 – the lever of the central switch of light of headlights can be installed in the following provisions: I – all consumers are switched off; II – are included lamps of dimensional light in headlights and back lamps and lamps of illumination of registration plate; By III – light of headlights is included distant or near (depending on position of the lever 20);

22 – the index of level of fuel, works at the included ignition. On a scale the zone of a reserve (R) corresponding to the reserve rest of fuel in a tank (about 12 l) is put;
23 – the block of control lamps in a combination of devices;
24 – speedometer. The scale has divisions from 0 to 220 km/h. The price of division is 5 km/h. The counter of total run and the counter of daily run are built in a speedometer. Counters show the way passed by the car in hundreds of meters. The counter of daily run is set to zero by pressing the button in the bottom of a speedometer at the motionless car;
25 – control lamps of an overheat of cooling liquid (top), the level of brake fluid in a tank of the main cylinder of a brake and level of liquid in a tank of the hydraulic booster of the steering mechanism (lower);
26 – electronic clock. Time conversion is made by two buttons located on the right and to the left of hours. When pressing the left button clock, on the right – is put minutes;
27 – the tachometer, shows the frequency of rotation of a cranked shaft of the engine. The scale has divisions from 0 to 80. The price of division is equal 2. To learn the frequency of rotation of the crankshaft, it is necessary to increase indications of a tachometer on 100. The red zone between divisions 63 and 80 corresponds to dangerous power setting in this range of frequencies of rotation of a cranked shaft. Depending on a car complete set instead of a tachometer an analog watch can be established;
28 – the index of temperature of cooling liquid, works at the included ignition. At the beginning of a scale of the device the zone of warming up of the engine is noted. The zone between 80 and 100 °C is a zone of the normal thermal mode of the engine. The zone between 100 and 120 °C is an engine overheat zone;
29 – switch of illumination of devices;

30 – the lever of the switch of the alarm system, turns on the alarm system when moving up. Thus the control lamp in a combination of devices lights up the red blinking light;
31 – the lever of the switch of screen wipers and a washer of a windshield, can be installed in the following provisions: I – all consumers are switched off; By II – the faltering operating mode of a screen wiper is included; By III – the small speed of work of a screen wiper is included; By IV – the maximum speed of work of a screen wiper is included; V – (on itself) the windshield washer is included. This position of the lever not fixed. At an otpuskaniye the lever comes back to a starting position;
32 – regulator of heating of forward seats. Turn of the left regulator the heating joins and temperature of heating of a seat of the driver, by turn of the right – the passenger's seats is regulated;
33 – switch and switch of operating modes of the on-board computer;
34 – disk of control of the gate of the central vozdukhoduv;
35 – central vozdukhoduv.
